Home > High Voltage Products >

S11 Three Phase Oil Immersed Oil-Immersed Type Transformer Oil-Filled Electric Transformer

Product Categories

Yueqing Yomin Electric Co., Ltd

Contact Now

Buy cheap S11 Three Phase Oil Immersed Oil-Immersed Type Transformer Oil-Filled Electric Transformer from wholesalers

Buy cheap S11 Three Phase Oil Immersed Oil-Immersed Type Transformer Oil-Filled Electric Transformer from wholesalers

S11 Three Phase Oil Immersed Oil-Immersed Type Transformer Oil-Filled Electric Transformer

Ask Lasest Price
Brand Name :	YOMIN
Model Number :	S11
Certification :	ISO9001,CE
Supply Ability :	1000 Piece/Pieces per Month
Price :	$800.00 - $17,000.00/Pieces

Add to Cart

Product Details
Company Profile

S11 Three Phase Oil Immersed Oil-Immersed Type Transformer Oil-Filled Electric Transformer

S11 Three Phase Oil Immersed Oil-Immersed Type Transformer Oil-Filled Electric Transformer

Technical parameters

Rated capacity	Installation dimension
(KVA)	L	W	H	C1	C2
30	980	870	1230	550	550
50	1010	900	1280	550	550
63	1030	920	1310	550	550
80	1050	930	1370	550	550
100	1070	970	1420	550	550
125	1090	990	1430	550	550
160	1130	990	1470	660	660
200	1150	1010	1520	660	660
250	1200	1080	1570	660	660
315	1210	1100	1620	660	660
400	1420	900	1730	660	660
500	1450	920	1790	820	820
630	1550	1000	1950	820	820
800	1700	1040	1990	820	820
1000	1780	1130	2050	820	820
1250	1880	1230	2100	820	820
1600	2040	1380	2260	820	820
2000	2350	1180	2600	1070	1070
2500	2450	1220	2720	1070	1070

Rated capacity	Voltage combination			Connection group	Loss (KW)		No-load current	Short-circuit impedance	Weight (kg)
kVA	HV kV	High-voltage tapping range	LV kV	symbol	No-load	On-load	%	%	Oil weight	Gross weight
30	20/10	±5×2.5% ±2×2.5%	0.4	Dyn11	0.09	0.66	2.1	5.5	260	640
50					0.13	0.96	2.0		280	720
63					0.15	1.145	1.9		290	760
80					0.18	1.37	1.8		310	830
100					0.2	1.65	1.6		330	920
125					0.24	1.98	1.5		340	990
160					0.29	2.42	1.4		360	1090
200					0.33	2.86	1.3		390	1230
250					0.4	3.35	1.2		430	1380
315					0.48	4.01	1.1		470	1610
400					0.57	4.73	1.0		500

Quality S11 Three Phase Oil Immersed Oil-Immersed Type Transformer Oil-Filled Electric Transformer for sale

S11 Three Phase Oil Immersed Oil-Immersed Type Transformer Oil-Filled Electric Transformer
